InteliLite4 AMF20 Global Guide
601
Operating temperature -30 °C to +70 °C
Dimensions (W × H × D) 110 × 110 × 46 mm (4.3” × 4.3” × 1.8”)
Weight 240 grams
Number of channels 2
Voltage
Range 0-10 V
Accuracy: ±20 mV + ±0.5 % of actual value
Imax 5 mA
Current
Range: 0-20 mA
Accuracy: ±100 µA + ±0.5 % of actual value
Rmax 500 Ω
PWM
Level 5 V
Frequency – adjustable 200÷2400 Hz
Imax 20 mA
Analog outputs
Number of channels 8 for Inteli IO8/8, 16 for Inteli IO16/0
Input resistance 4400 Ω
Input range 0 to 36 V DC
Switching voltage level for open contact
indication
0 to 2 V DC
Max voltage level for close contact
indication
6 to 36 V DC
Binary inputs
Number of channels 8 for Inteli IO8/8, 0 for Inteli IO16/0
Max current 500 mA
Max switching voltage 36 V DC
Binary outputs
IGS-PTM
IGS-PTM module is extension module equipped with binary inputs, binary outputs, analog inputs and analog
output. IGS-PTM module is connected to controller by CAN1 bus.
