ComAp InteliLite AMF25 - Page 249

InteliLite Global Guide
249
Setpoint group Generator settings Related FW 1.9.0
Range [units] 0,0 .. Generator Underfrequency Wrn (page 249) [%]
Default value 85,0 % Alternative config NO
Step 0,1 % of Nominal Frequency (page 196)
Comm object 8298 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator phase L1 underfrequency.
Note: When there is no control of breakers, the type of protection is Sd not BOC.
Generator Underfrequency BOC
6 back to List of setpoints
Setpoint group Generator settings Related FW 1.9.0
Range [units]
Generator Underfrequency BOC (page 249) .. Generator Overfrequency Wrn
(page 248) [%]
Default value 85,0 % Alternative config NO
Step 0,1 % of Nominal Frequency (page 196)
Comm object 9689 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator phase L1 underfrequency.
Generator Underfrequency Wrn
6 back to List of setpoints
Setpoint group Generator settings Related FW 1.9.0
Range [units] 0,0 .. 600,0 [s]
Default value 3,0 s Alternative config NO
Step 0,1 s
Comm object 8297 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Delay for Generator Overfrequency BOC (page 248), Generator Overfrequency Wrn (page 248),
Generator Underfrequency Wrn (page 249) and Generator Underfrequency BOC (page 249)
protection.
Generator <> Frequency Delay
6 back to List of setpoints
