InteliLite Global Guide
263
Setpoint group AMF settings Related FW 1.9.0
Range [units] Mains Fail / Gen Run [-]
Default value Gen Run Alternative config NO
Step [-]
Comm object 9850 Related applications AMF
Config level Advanced
Setpoint visibility Conditioned by the setpoint Operation Mode (page 199)
Description
Setpoint adjust the behavior of opening MCB in AUTO mode when there is mains fail.
Mains Fail The command to open the MCB is given immediately after mains fail condition is evaluated.
If the mains will return into parameters after MCB was opened and before GCB is closed, timer
MCB Close Delay (page 257) is applied before MCB closing.
Gen Run MCB will be opened when engine will be running and it will be possible to transfer load from
Mains to gen-set (after stabilisation phase).
Note: This option should be used for MCBs using 230V control and not equipped with the undervoltage
coil.
MCB Opens On
6 back to List of setpoints
Group: Dual Operation
Subgroup: Dual Operation
Setpoint group Dual Operation Related FW 1.9.0
Range [units] 0,1 .. 1000,0 [h]
Default value 10 h Alternative config NO
Step 0,1 h
Comm object 16039 Related applications AMF, MRS
Config level Advanced
Setpoint visibility
Only if relevant module is installed + conditioned by the setpoint COM1 Mode (page
367) and COM2 Mode (page 369)
Description
This setpoint adjusts the maximal allowed difference of dual operation running hours between Master and
Slave. When difference is higher, swap of load between controllers should be done.
Running Hours Max Difference
6 back to List of setpoints
