ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
323
Setpoint group Geo-Fencing Related FW 1.9.0
Range [units] 0,0..99,9 [km]
Default value 0,0 km Alternative config NO
Step 0,1 km
Comm object 11677 Related applications AMF, MRS
Config level Standard
Setpoint visibility Only if relevant module is installed
Description
Radius for circle area 1. When the gen-set leaves this area, Fence 1 Protection (page 325) is activated
after Fence 1 Delay (page 323).
Note: The center of this circle area is defined by "Home" position - setpoints Home Longitude (page
322) and Home Latitude (page 322).
Fence Radius 1
6 back to List of setpoints
Setpoint group Geo-Fencing Related FW 1.9.0
Range [units] 0,0..99,9 [km]
Default value 0,0 km Alternative config NO
Step 0,1 km
Comm object 14608 Related applications AMF, MRS
Config level Standard
Setpoint visibility Only if relevant module is installed
Description
Radius for circle area 2. When the gen-set leaves this area, Fence 2 Protection (page 326) is activated
after Fence 2 Delay (page 324).
Note: The center of this circle area is defined by "Home" position - setpoints Home Longitude (page
322) and Home Latitude (page 322).
Fence Radius 2
6 back to List of setpoints
Setpoint group Geo-Fencing Related FW 1.9.0
Range [units] 0..3600 [s]
Default value 0 s Alternative config NO
Step 1 s
Comm object 11682 Related applications AMF, MRS
Config level Standard
Setpoint visibility Only if relevant module is installed
Description
Delay for Fence 1 Protection (page 325).
Fence 1 Delay
6 back to List of setpoints

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
