ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
336
Setpoint group Basic settings Related FW 1.9.0
Range [units] 100 .. 4000 [RPM]
Default value 1 500 RPM Alternative config YES
Step 1 RPM
Comm object 9916 Related applications AMF, MRS
Config level Advanced
Setpoint visibility Always
Description
Nominal engine speed (RPM - revolutions per minute).
Note: This value is used when binary input ALTERNATE CONFIG 2 (PAGE 499) is active.
Nominal RPM 2
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.9.0
Range [units] 80 .. 20000 [V]
Default value 231 V Alternative config YES
Step 1 V
Comm object 12053 Related applications AMF, MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Connection type 2 (page 333).
Description
Nominal system voltage (phase to neutral).
Note: This value is used when binary input ALTERNATE CONFIG 2 (PAGE 499) is active.
Nominal Voltage Ph-N 2
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.9.0
Range [units] 80 .. 40000 [V]
Default value 400 V Alternative config YES
Step 1 V
Comm object 12056 Related applications AMF, MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Connection type 2 (page 333).
Description
Nominal system voltage (phase to phase).
Note: This value is used when binary input ALTERNATE CONFIG 2 (PAGE 499) is active.
Nominal Voltage Ph-Ph 2
6 back to List of setpoints

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
