InteliLite Global Guide
410
Setpoint group EM-BIO8-EFCP Related FW 1.9.0
Range [units] 0,03 .. 5,00 [s]
Default value 0,10 s Alternative config NO
Step 0,01 s
Comm object 11633 Related applications AMF, MRS
Config level Standard
Setpoint visibility Only if relevant module is installed
Description
Delay for Earth Fault Current protection.
Earth Fault Delay
6 back to List of setpoints
Setpoint group EM-BIO8-EFCP Related FW 1.9.0
Range [units] 1 [A] / 5 [A]
Default value 5 A Alternative config NO
Step [-]
Comm object 14340 Related applications AMF, MRS
Config level Standard
Setpoint visibility Only if relevant module is installed
Description
There are 2 physical inputs for Earth Fault Current Protection (page 409). Value of this setpoint has to be
set on value of physical input which is presently in use.
Earth Fault CT Input Range
6 back to List of setpoints
Setpoint group EM-BIO8-EFCP Related FW 1.9.0
Range [units] 1 .. 2000 [1/(1or5)A]
Default value 500 1/(1or5)A Alternative config NO
Step 1A/1A; 1A/5A
Comm object 14339 Related applications AMF, MRS
Config level Standard
Setpoint visibility Only if relevant module is installed
Description
Earth Fault current transformer ratio.
Note: Type of units depends on setpoint Earth Fault CT Input Range (page 410) which have to be set
before this setpoint.
Earth Fault CT Ratio
