ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
545
Related FW 1.9.0 Related applications AMF, MRS
Comm object 3
Description
Output closes when any warning alarm appears.
The output opens, if:
No warning alarm is active and
Fault reset button is pressed
AL Common Wrn
6 back to Logical binary outputs alphabetically
Related FW 1.9.0 Related applications AMF, MRS
Comm object 1295
Description
The output is closed when there is the Wrn Coolant Temperature Low (page 656) alarm from the
COOLANT TEMP (PAGE 631) in the alarmlist or isn’t confirmed.
AL CoolantTemp Low
6 Logical binary outputs alphabetically (page 539)
Related FW 1.9.0 Related applications AMF, MRS
Comm object 1421
Description
The output is closed when there is the shutdown or BOC alarm from the COOLANT TEMP (PAGE 631) in the
alarmlist or isn’t confirmed.
AL CoolantTemp Sd
6 Logical binary outputs alphabetically (page 539)
Related FW 1.9.0 Related applications AMF, MRS
Comm object 1420
Description
The output is closed when there is the warning alarm from the COOLANT TEMP (PAGE 631) in the alarmlist or
isn’t confirmed.
Note: Binary output is also active if protection type is set to HistRecOnl and threshold level for history
record is reach.
AL CoolantTemp Wrn
6 back to Logical binary outputs alphabetically

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
