ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
668
Alarm Type Other
Alarmlist message EM(B) - missing or damaged
Alarm evaluated All the time
Related applications AMF, MRS
Description
This alarm indicates that there is a problem with communication with module in slot
(in first 5 second there was no communication and module is configured in slot).
EM(B) - missing or damaged
6 back to List of alarms level 1
Alarm Type Warning
Alarmlist message Generator CCW Rotation
Alarm evaluated All the time
Related applications AMF, MRS
Description
The controller detects phase sequence on generator voltage terminals. This
protection is important after controller installation to avoid wrong voltage phase
connection. There is a fixed defined phase sequence in InteliLite controller: T35 =
N, T36 = L1, T37 = L2 and T38 = L3. When the phases are connected in a different
order, alarms are detected. This alarm prevent circuit breaker closing.
Generator CCW Rotation
6 back to List of alarms level 1
Alarm Type Other
Alarmlist message Module(slotA) - comm. outage
Alarm evaluated All the time
Related applications AMF, MRS
Description
This alarm indicates that there is a problem with communication between controller
and module in slot.
Module(slotA) - comm. outage
6 back to List of alarms level 1
Alarm Type Other
Alarmlist message Module(slotA) - fake module
Alarm evaluated All the time
Related applications AMF, MRS
Description This alarm indicates that false module is inserted in slot.
Module(slotA) - false module
6 back to List of alarms level 1

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
