ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
230
Setpoint group Generator settings Related FW 1.9.0
Range [units] 1 .. 200 [%] of Nominal Current (page 176)
Default value 50 % Alternative config NO
Step 1 % of Nominal Current (page 176)
Comm object 8284 Related applications AMF, MRS
Config level Advanced
Setpoint visibility Conditioned by the setpoint Connection type (page 177)
Description
Threshold for generator current asymmetry (unbalance).
Protection is BOC (Breaker Open and genset Cooldown).
Note: When there is no control of breakers, the type of protection is Sd not BOC.
Current Unbalance BOC
6 back to List of setpoints
Setpoint group Generator settings Related FW 1.9.0
Range [units] 0,0 .. 600,0 [s]
Default value 5,0 s Alternative config NO
Step 0,1 s
Comm object 8285 Related applications AMF, MRS
Config level Advanced
Setpoint visibility Conditioned by the setpoint Connection type (page 177)
Description
Delay for Current Unbalance BOC (page 230) protection.
Current Unbalance BOC Delay
6 back to List of setpoints
Subgroup: Voltage Protection
Setpoint group Generator settings Related FW 1.9.0
Range [units] Generator Overvoltage Wrn (page 231) .. 200 [%]
Default value 110 % Alternative config NO
Step 1 % of Nominal Voltage Ph-N (page 179) or Nominal Voltage Ph-Ph (page 179)
Comm object 8291 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator overvoltage protection. All three phases are checked. Maximum out of three is used.
Note: Phase to phase and phase to neutral voltages are used for this protection.
Generator Overvoltage Sd
6 back to List of setpoints

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
