Comau Robotics Product Instruction
48
ROBOT CONFIGURATION CUSTOMIZATION
c. Fix the base flange (A) of the
e.DO Marker Holder on the
e.DO flange (B), using 4 socket
hex head screws (E) M3x8 and
interposing the corresponding
washers, supplied with the
e.DO Marker Holder.
d. Tighten the fixing screws to the
torque of 0.5 Nm.
e. Fix the marker and the marker
holder as indicated in the
procedure on How to fix the
marker on the e.DO Marker
Holder (see par. 6.2.5 on
page 57) in the User Manual.
Operating procedure (Continued)
