JHL90 Service Manual
Offset Description
Bit3 - Battery shutdown 5%
Bit4 - Start to read battery
Bit5 - Start to count communication counter
F2h
Battery stop charge status (low byte)
Bit0 - Battery fast charging timeout
Bit1 - Battery bad cell
Bit2 - Battery communication fail
Bit3 - Use for detect battery charging suspend
Bit4 - Battery command stop charge
Bit5 - Battery stop charge for Customer use
Bit6 - Battery over voltage
Bit7 - Battery over temperature
F3h
Battery stop charge status (high byte)
Bit0 - Battery trickle charging timeout
Bit1 - Stop charge of Adapter throttling
Bit2 - Stop charge of Sony battery
Bit3 - Stop charge of adapter loading
Bit4 - Stop charge of flash
F4h-F5h
ManufactureDate
F6h-F7h
Charging Voltage
F8h
Battery Cell number
Bit0 - Set Battery is 3 cells
Bit1 - Set Battery is 4 cells
Bit2 - Set Battery is 6 cells
Bit3 - Set Battery is 8 cells
Bit4 - Set Battery is 9 cells
Bit5 - Set Battery is 12 cells
F9h-FFh
Reserved
12.17.8 Control method for 2
nd
battery pack RAM definition
Offset Description
20h
Battery status
Bit7 - Battery type
21h
Battery Status
Bit0 - Discharging
Bit1 - Charging
Bit2 - Discharging and Now is critical low
Bit3 - Low battery
Bit7 - AC status
22h-23h
Remaining Capacity
24h-25h
Serial Number
26h-27h
Present Voltage
28h-29h
Design Voltage
2Ah-2Bh
Design Capacity
2-43
