JHL90 Service Manual
Offset Description
C8h-C9h
Design Voltage
CAh-CBh
Design Capacity
CCh-CDh
Full charge capacity
CEh
Gasgauge
CFh
Battery cycle counter
D0h-D1h
Battery current
D2h-D3h
Battery average current
D4h
System power comsumption
D5h
Battery Volt
D6h
Battery Temp
D7h
Battery Average Temp
D8h-D9h
Battery charge currrent
DAh
Battery current Temp sample counter
DBh
Battery Command index for read battery through SMBus
DCh
Count up to communicate battery
DDh
Count up if battery is arrived overtemp
DEh-DFh
SMBus status
E0h
Battery over voltage counter
E1h
Communicatiion fail counter
E2h
Battery voltage of ADC
E3h-E4h
Cell1 voltage
E5h-E6h
Cell2 voltage
E7h-E8h
Cell3 voltage
E9h-EAh
Cell4 voltage
F0h
Battery staus1
Bit0 - Battery exist
Bit1 - Battery full
Bit2 - Battery empty
Bit3 - Battery first in
Bit4-5 - reserved
Bit6 - Battery read complete
Bit7 - Use LI_ION or NI_MH#
F1h
Battery staus2
Bit0 - Low low battery
Bit1 - Check EDV1
Bit2 - Set EDV1
2-42
