JHL90 Service Manual
Offset Description
Bit7 - THROTTLING (1: Control HW throttling active)
B0h
CPU_TEMP: CPU current temperature
B1h
CPU_TEMP_LOCAL: CPU local temperature
B2h
SKIN_TEMP90: SKIN temperature address 90
B3h
OS Shutdown Temp. For system read setting. (VGA)
B4h
VGA_TEMP: VGA temperature
B5h
CPU_DTS: CPU DTS temperature
B6h
NorthBridge temperature
B7h
Reserved
B8h
Reserved
B9h
Lcd brightness value (0x00-0x07)
BAh
Lcd contrast value (0x00-0x1F)
BBh
Device module status
Bit0 - 1=Wirless LAN active, 0=Wirless LAN no active
Bit1 - 1=BlueTooth active, 0=BlueTooth no active
Bit2 - 1=Wirless LAN exist, 0=Wirless LAN no exist
Bit3 - 1=BlueTooth exist, 0=BlueTooth no exist
Bit4 - 1=Kill switch on, 0=Kill switch off
Bit5 - 1=WireLess LAN initial OK
BCh
KbProjectID: Project ID
BDh
CPU_TYPE: CPU type
BEh
Reserved
BFh
Reserved
12.17.7 Control method for 1
st
battery pack RAM definition
Offset Description
C0h
Battery status
Bit7 - Battery type
C1h
Battery Status
Bit0 - Discharging
Bit1 - Charging
Bit2 - Discharging and Now is critical low
Bit3 - Low battery
Bit7 - AC status
C2h-C3h
Remaining Capacity
C4h-C5h
Serial Number
C6h-C7h
Present Voltage
