Compaq Evo D500 User Manual

Technical Reference Guide
Appendix D
COMPAQ/NVIDIA TNT2 PRO
AGP GRAPHICS CARD
D. Appendix D Compaq/NVIDIA TNT2 Pro AGP Graphics Card
D.1 INTRODUCTION
This appendix describes the Compaq/NVIDIA TNT2 Pro AGP Graphics Card used in the
standard configuration on some models and also available as an option. This card (layout shown
in the following figure) installs in a system’s AGP slot. The Compaq/NVIDIA TNT2 Pro
graphics card (P/N 189998-B21) provides high 2D performance as well as 3D capabilities.
Feature Connector
Analog
Monito
r
Connector
SGRAM
SGRAM
SGRAM
NVIDIA
TNT2
Controller
SGRAM
Figure D-1. Compaq/NVIDIA TNT2 Pro AGP Graphics Card (P/N 198998-B21) Layout
This appendix covers the following subjects:
♦ Functional description (D.2) page D-2
♦ Display modes (D.3) page D-3
♦ Software support information (D.4) page D-4
♦ Monitor power management (D.5) page D-4
♦ Connectors (D.6) page D-5
Compaq Personal Computers
Original - July 2000
D-1
