Chapter 2 System Overview
2.4.2 CHIPSET
The Intel 815E chipset consists of a Graphics Memory Controller Hub (GMCH), an enhanced I/O
controller hub (ICH2), and a firmware hub (FWH). Table 2-2 lists the integrated functions
provided by the chipset.
Table 2-2. Chipset Comparison
Table 2-2.
815E Chipset Functions
Component Type Function
82815 GMCH AGP 4X interface
Direct AGP graphics controller
SDRAM controller supporting 3 PC133 DIMMs
66-/100-/133-MHz FSB
82801BA ICH2 PCI bus I/F
LPC bus I/F
SMBus I/F
IDE I/F with UATA/100 support
AC ’97 controller
RTC/CMOS
IRQ controller
Power management logic
USB I/F (2)
Network interface controller
82802 FWH Loaded with Compaq BIOS
Random number generator
2.4.3 SUPPORT COMPONENTS
Input/output functions not provided by the chipset are handled by other support components.
Some of these components also provide “housekeeping” and various other functions as well.
Table 2-3 shows the functions provided by the support components.
Table 2-3. Support Component Functions
Table 2-3.
Support Component Functions
Component Name Function
LPC47B357 I/O Controller Keyboard and pointing device I/F
Diskette I/F
Serial I/F (COM1and COM2)
Parallel I/F (LPT1, LPT2, or LPT3)
AGP, PCI reset generation
Interrupt (IRQ) serializer
Power button logic
GPIO ports
AD1885 Audio Codec [1] Audio mixer
Digital-to-analog converter
Analog-to-digital converter
Analog I/O
NOTE:
[1] Systems with embedded AC97 audio.
Compaq Deskpro and Evo Personal Computers
Featuring Intel Celeron and Pentium III Processors
Fifth Edition – March 2002
2-16
