Compaq Evo D500 - 2.2 FEATURES AND OPTIONS

Chapter 2 System Overview
2.2 FEATURES AND OPTIONS
This section describes the standard features and available options.
2.2.1 STANDARD FEATURES
The following standard features are included on all models:
♦ Intel Pentium III or Celeron processor in FC-PGA370 package
♦ Intel 815E Chipset
♦ Instantly Available PC
♦ Support for three PC133 DIMMs
♦ 3.5 inch, 1.44-MB diskette drive
♦ 48x Max CD-ROM drive
♦ IDE controller w/UATA/100 mode support
♦ Hard drive fault prediction
♦ Two serial, two USB, one parallel, and one network interface
♦ APM 1.2 power management support
♦ Plug ’n Play compatible (with ESCD support)
♦ Intelligent Manageability support
♦ Energy Star compliant
♦ Security features including:
• Flash ROM Boot Block
• Diskette drive disable, boot disable, write protect
• Power-on password
• Administrator password
• Serial/parallel port disable
♦ PS/2 Compaq Easy-Access keyboard w/Windows support
♦ PS/2 Compaq Scroll Mouse
Table 2-1 shows the differences in features between the Deskpro series’ based on form factor:
Table 2-1. Feature Difference Matrix
Table 2-1.
Feature Difference Matrix (by Form Factor)
Small Form Factor Slim Desktop Configurable Minitower [1]
Series Deskpro EN / Evo D500 Deskpro EN Deskpro EN / Wkstn. AP230
Chassis type Compaq Proprietary ATX ATX
Drive bays 3 5 5
Audio [2] Premier Sound Business Audio Business Audio
Front panel audio access Yes No No
AGP slot No Yes Yes
# of PCI slots 3 5 5
Smart Cover Sensor/Lock Yes Yes No
Power Supply 120 watt 200 watt 200 watt
NOTES:
[1] Unit may be configured as desktop or minitower.
[2] Systems with integrated AC97 sound. Some systems without integrated
AC97 sound circuitry (legacy beep-audio only).
Compaq Deskpro and Evo Personal Computers
Featuring Intel Celeron and Pentium III Processors
Fifth Edition – March 2002
2-2
