Compaq Evo D500 User Manual

Technical Reference Guide
Appendix G
COMPAQ/ADAPTEC 29160N SCSI HOST ADAPTER
G.
Appendix G Compaq/Adaptec SCSI Host Adapter
G.1 INTRODUCTION
The Compaq/Adaptec 29160N SCSI Host Adapter (Compaq SP# 158364-001) is a PCI peripheral
that provides high performance interfacing with compatible SCSI peripherals, typically SCSI hard
drives. The card installs in a PCI slot and supports full bus mastering capability.
This appendix covers the following subjects:
♦ Functional description (G.2) page G-2
♦ SCSI adapter programming (G.3) page G-3
♦ Specifications (G.4) page G-3
♦ SCSI connectors (G.5) page G-4
AIC7892
Internal
Ultra SCSI Connector
Internal
Wide-Ultra SCSI Connector
External
Ultra
SCSI Connecto
r
Figure G–1. Compaq/Adaptec 29160N SCSI Host Adapter Card Layout (PCA# 157342-001)
Compaq Personal Computers
Original - December 2000
G-1
