Item
Qty
CEFD Part No.
Description
1
1
SW/WGS28V-75SB
SWITCH, WAVEGUIDE, WR75, +28VDC, SEALED, SIDE & BOTTOM MNT
2
1
RF/TRF-KU-WR75G
RF TRANSMIT REJECT, WR75, GROOVED
3
7
GA/GSKTWR75HALF
GASKET, WR75, HALF THK
4
1
FP/6072
PLATE, SHORTING, WR75G
5
2
99D1483
ASSY, WAVEGUIDE WR75
6
24
HW/6-32X1/2SHCS
#6-32 x 1/2 LG SOCKET HD CAP SCREW, SS
7
12
HW/6-32X7/8SHCS
#6-32 x 7/8 LG SOCKET HD CAP SCREW, SS
8
28
HW/6-SPLIT
#6 SPLIT LOCK WASHER, SS
9
40
HW/6-FLT
#6 FLAT WASHER, SS
10
12
HW/6-32HEXNUT
#6-32 HEX NUT, SS
11
3
HW-0000313
GASKET, WR75, FLAT, CONDUCTIVE
Figure A-8. PL/7596-1 LPOD Ku-Band Rx Switch Kit Example – Exploded Isometric View
