Comtech EF Data LPOD Series - Summary of Specifications; Characteristics

Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Revision 15
Introduction 1–8 MN-LPOD
1.5 Summary of Specifications
1.5.1 Characteristics
IF Input Frequency
1
RF Output Frequency
950 – 1525 MHz
5.850 – 6.425 GHz
950 – 1750 MHz
5.850 – 6.650 GHz (optional)
950 – 1825 MHz
5.850 – 6.725 GHz (optional)
965 – 1265 MHz
6.725 – 7.025 GHz
950 – 1450 MHz
7.900 – 8.400 GHz
950 – 1450 MHz
12.75 – 13.25 GHz
950 – 1450 MHz
14.00 – 14.50 GHz
950 – 1750 MHz
13.75 – 14.50 GHz (optional)
Model
Psat (Typical)
P1dB (Guaranteed)
Note 2
Ku-Band
PS 1 – 20 Ku
43 dBm (20 W)
42 dBm (16 W)
PS 1 – 32 Ku
45 dBm (32 W)
44 dBm (25 W)
PS 1 – 40 Ku
46 dBm (40 W)
45 dBm (32 W)
PS 1.5 – 50 Ku
47 dBm (50 W)
46 dBm (40 W)
PS 1.5 – 60 Ku
48 dBm (60 W)
47 dBm (50 W)
PS 2 – 100 Ku
50 dBm (100 W)
49 dBm (80 W)
PS 2 – 125 Ku
51 dBm (125 W)
50 dBm (100 W)
C-Band
or
X-Band
PS 1 – 25 C, X
44 dBm (25 W)
43 dBm (20 W)
PS 1 – 32 C, X
45 dBm (32 W)
44 dBm (25 W)
PS 1 – 4 0 C, X
46 dBm (40 W)
45 dBm (32 W)
PS 1 – 50 C, X
47 dBm (50 W)
46 dBm (40 W)
PS 1 – 60 C, X
48 dBm (60 W)
47 dBm (50 W)
PS 1.5 – 75 C, X
48.6 dBm (75 W)
48 dBm (60 W)
PS 1.5 – 80 C, X
49 dBm (80 W)
48.5 dBm (70 W)
PS 1.5 – 100 C, X
50 dBm (100 W)
49 dBm (80 W)
PS 1.5 – 110 C, X
50.4 dBm (110 W)
49.5 dBm (90 W)
PS 1.5 or PS 2 – 125
C, X
51 dBm (125 W)
50 dBm (100 W)
PS 2 – 150 C, X
51.8 dBm (150 W)
51 dBm (125 W)
PS 2 – 200 C, X
53 dBm (200 W)
52.5 dBm (175 W)
PS 2 – 250 C, X
54 dBm (250 W)
53 dBm (200 W)
PS 2 – 300 C
55 dBm (300 W)
54 dBm (250 W)
Notes:
1. PS 2 Models are available as SSPAs only, without internal L-Band BUC (Freq RF in = Freq RF out).
2. Allow 1 dB degradation from 13.75 to 14.0 GHz and 6425 to 6725 MHz
