Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Revision 15
Appendix B B-2 MN-LPOD
B.2 Control and Data Cables
Figure
Cable P/N
Description Used For:
REF App A
Figure
Figure
B-1
CA-0020526
Serial Interface Cable
(19-pin circular connector to RJ-11)
Connecting 1:1 Redundant Loop Cable ‘J1’ receptacle or Standalone LPOD ‘J6 |
COM1’ receptacle to CLC-10 RJ-11 communications jack
(Cable and CLC-10 are furnished as part of optional CEFD KIT KT-0020518)
A-2, A-3, A-12
through A-29
Figure
B-2
CA-0000352
Ethernet Interface Cable
(19-pin circular connector to <2X> RJ-45)
Connecting 1:1 Redundant Loop Cable ‘J1’ receptacle or Standalone LPOD ‘J6 |
COM1’ receptacle to LPODnet Ethernet jack
(Cable and LPODnet are furnished as part of optional CEFD KIT KT-0000203)
A-1, A-3, A-12
through A-29
Figure
B-3
CA-0000318
100’ COMMS Cable
(19-pin circular connector to bare end)
Connecting 1:1 Redundant Loop Cable ‘J1’ receptacle or Standalone LPOD ‘J6 |
COM1’ receptacle to user-specified M&C interface
A-3, A-
A-29
Figure
B-4
CA-0000543
250’ COMMS Cable
(19-pin circular connector to bare end)
A-3, A-
A-29
Figure
B-5
CA-0020655
Rx / Tx Redundant Loop Cable
(19-pin circular receptacle to <2X> Type ‘N’
connectors, <2X> 19-pin circular
connectors)
Interconnecting 1:1 Redundancy System LPOD units, Rx / Tx switches, and user M&C
interface
A-3, A-
A-29
Figure
B-6
CA-0020657
Tx-only Redundant Loop Cable
(19-pin circular receptacle to <1X> Type ‘N’
connector, <2X> 19-pin circular connectors)
Interconnecting 1:1 Redundancy System LPOD units, Tx switch, and user M&C
interface
A-3, A-
A-29
