Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)

Revision 15

System Connectors, Installation, and Startup 2–1 MN-LPOD

Chapter 2. SYSTEM

CONNECTORS, INSTALLATION,

AND STARTUP

2.1 Overview

•

See Chapter 4. ETHERNET INTERFACE OPERATION for information about

using the LPOD’s remote Ethernet M&C functionality.

• See Chapter 5. SERIAL INTERFACE OPERATION for information about using

serial-based remote commands and queries.

• See Appendix A. 1:1 REDUNDANCY for detailed information for installing and

using the LPODs in a 1:1 redundancy configuration.

This chapter provides user reference to the following:

• The LPOD connectors for signal input, signal output; M&C of the unit; and grounding of

the unit to the antenna’s grounding network.

• Available standalone installation kits.

• Instructions for installation and startup.
