Comtech EF Data LPOD Series - Shelf-Mounted Single Unit Kit (KT-0020524) for PS 2

Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Revision 15
System Connectors, Installation, and Startup 2–22 MN-LPOD
2.4.5 Shelf-Mounted Single Unit Kit (KT-0020524) for PS 2
Use Kit KT-0020524 to install the PS 2 on a shelf.
Item
Qty
CEFD Part Number
Description
1
1
FP-0020545
BRACKET, MOUNTING
2
2
HW/5/16-FLT
FLAT WASHER, 5/16
3
2
HW/5/16-SPLIT
LOCK WASHER, SPLIT 5/16
4
2
HW/5/16-18X3/4B
BOLT, HEX HEAD, 5/16-18 X 3/4 LG
5
4
HW/3/8-FLT
FLAT WASHER, 3/8
6
4
HW/3/8-SPLIT
LOCK WASHER, SPLIT 3/8
7
2
HW/3/8-16X1B
BOLT, HEX HEAD, 3/8-16 X 1 LG
8
2
HW/3/8-16X1.25B
BOLT, HEX HEAD, 3/8-18 X 1.25 LG
Figure 2-14. Shelf Mounted, Single Unit Kit (KT-0020524) for PS 2
