Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Revision 15
System Connectors, Installation, and Startup 2–20 MN-LPOD
2.4.4 Spar-Mounted Installations for PS 1, PS 1.5
PS 2 units may not be spar-mounted due to weight considerations.
PS 1 and PS 1.5 standalone configurations, in addition to satellite dish support pole mounted
installations, may be installed on the antenna spar. Figure 2-12 shows a typical CEFD spar mount
SSPA installation.
The kit that is required for the installation of your LPOD system (Figure 2-13) is determined by the
spar that is used by the antenna’s manufacturer.
Figure 2-12. SSPA Spar Mount Installation Example
