Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Revision 15
Appendix A A–49 MN-LPOD
Item
Qty
CEFD Part No.
Description
1
1
FP-0001170
WAVEGUIDE, Ku-BAND, WR-75, LH, 1:1, LPOD PS 2
2
1
FP-0001171
WAVEGUIDE, Ku-BAND, WR-75, RH, 1:1. LPOD PS 2
3
4
FP-0000442
BRACK, MOUNTING, HPOD & LPOD PS 2
4
2
FP-0000543
CHANNEL, DUAL, UNISTRUT, 1:1 RDNT, LPOD PS 2
5
1
FP-0000626
BRACKET, RF SW, UNIVERSAL, 1:1 RED., LPOD PS 2
6
2
FP-0000580
SPACER PLATE, RF SPLITTER / COMBINER
8
1
FP-0000762
SUPPORT BRACKET, 1:1 REDUNDANCY, LPOD PS 2
12
1
HW/CAP-SS14
DUST COVER,RECEPTACLE,NON-SHORTING, SIZE 14, SS,W/CHAIN & RING
20
1
SW/WGS28V-75SB
SWITCH, WAVEGUIDE, WR75, +28VDC, SEALED, SIDE & BOTTOM MOUNT
21
1
RF/TERM-11923-5
RF TERMINATION, WR75G, 14-14.5GHz, 1.05:1 VSWR, 150W, FLAT BLACK, G
22
1
RF-0000105
RF POWER SPLITTER / COMBINER, 2-WAY, 0 DEGREES, 1-2GHZ
23
5
GA/GSKTWR75HALF
GASKET, WR75, HALF THICK
30
10
HW/3/8SPRINGNUT
SPRINGNUT, 3/8-16, SHORT SPRING, SS (P3300)
31
10
HW-0000070
3/8-16 x 3/4 LG SCREW, HEX, SERR FLNG HD, SS
33
2
HW/4-40X1.38PH
SCREW #4-40 x 1-3/8 LG PHILLIPS HD, SS
34
2
HW/4-SPLIT
#4 SPLIT LOCK WASHER, SS
35
2
HW/4-FLT
#4 FLAT WASHER, SS
39
24
HW/6-FLT
#6 FLAT WASHER, SS
40
24
HW/6-SPLIT
#6 SPLIT LOCK WASHER, SS
41
4
HW/6-32X5/16P.H
#6-32 x 5/16 LG PHILLIPS SCREW
42
16
HW/6-32X1/2SHCS
#6-32 x 1/2 LG SOCKET HD CAP SCREW, SS
43
4
03P1111
#6-32 x 9/16 LG SCREW, SOCKET HD, SS
44
2
HW/#10-32X1/2SH
#10-32 x 1/2 LG SOCKET HD CAP SCREW, SS
45
2
HW/10-SPLIT
#10 SPLIT LOCK WASHER, SS
46
2
HW/10-FLT
#10 FLAT WASHER, SS
47
8
HW/5/16-18X3/4B
5/16-18 x 3/4 LG HEX HD BOLT, SS
48
8
HW/5/16-SPLIT
5/16” SPLIT LOCK WASHER
49
8
HW/5/16-FLT
5/16” FLAT WASHER
Figure A-28. KT-0000254 LPOD PS 2 Ku-Band 1:1 Redundancy Kit Example – Exploded Isometric View
