CONCH HM Series User Manual

6 Instruction of the Wiring & Setting of Supported Communication Devices
93
HM Series Connection Manual
6.16. Mitsubishi A Series A1SH CPU
6.16.1. Register Type & Range:
Register Type
Code
Format
Numbering Range of Address
Data
Length
Input Relay
Xn
n = 0~7F0 (Hexadecimal, must be multiples of 10)
Word
Output Relay
Yn
n = 0~7F0 (Hexadecimal, must be multiples of 10)
Word
Link Relay
Bn
n = 0~3F0 (Hexadecimal, must be multiples of 10)
Word
Internal Relay
Mn
n = 0~984 (must be multiples of 16)
Word
Special Relay
Mn
n = 9000~9240
(must be multiples of 16 minus 9,000)
Word
Latch Relay
Ln
n = 0~2032 (must be multiples of 16)
Word
Annunciator
Fn
n = 0~240 (must be multiples of 16)
Word
Timer PV
TNn
n = 0~255
Word
Counter PV
CNn
n = 0~255
Word
Data Register
Dn
n = 0~1023
Word
Special Register
Dn
n = 9000~9255
Word
File Register
Rn
n = 0~8191
Word
Link Register
Wn
n = 0~3FF (Hexadecimal)
Word
Peripherial Input Relay
PXn
n = 0~240 (must be multiples of 16)
Word
