6.1 HM Series Internal Registers
HM Series Connection Manual
6.1.2. Contact Type & Range:
Contact Type
Code Format
Numbering Range of Address
Terminal Block
Internal Register Bit
@n.b
n = 0~8191, b = 0~15
b = 0
Memory Register Bit
@Mn.b
n = 0~1023, b = 0~15
b = 0
Control Block Bit
CBn.b
n = 0~31, b = 0~15
b = 0
Status Block Bit
SBn.b
n = 0~31, b = 0~15
b = 0
Extended Control Block Bit
ECn.b
n = 0~31, b = 0~15
b = 0
Extended Status Block Bit
ESn.b
n = 0~31, b = 0~15
b = 0
Recipe Data Bit
RCPWn.b
n = 0~65535, b = 0~15
b = 0
System Control Contact
SCn.b
n = 0~31, b = 0~7
b = 0
Internal Register Bit
*@n.b
n = 0~8191, b = 0~15
b = 0
Memory Register Bit
*@Mn.b
n = 0~1023, b = 0~15
b = 0
