HM Series Connection Manual
6.4. Facon FBs Series PLC
6.4.1. Register Type & Range:
Register Type
Code
Format
Numbering Range of Address
Data Length
Input Relay
WXn
n = 0~9984 (Must be multiples of 8)
Word
Output Relay
WYn
n = 0~9984 (Must be multiples of 8)
Word
Internal Relay
WMn
n = 0~9984 (Must be multiples of 8)
Word
Special Relay
WMn
n = 0~9984 (Must be multiples of 8)
Word
Step Relay
WSn
n = 0~9984 (Must be multiples of 8)
Word
Timer Present Value
RTn
n = 0~9999
Word
Counter Present Value
RCn
n = 0~9999
Word
Data Register
Rn
n = 0~65534
Word
32-bit Counter Present Value
DRCn
n = 200~255
DWord
Data Register
Dn
n = 0~65534
Word
6.4.2. Contact Type & Range:
Contact Type
Code
Format
Numbering Range of Address
Block
Input Relay
Xn
n = 0~9999
Multiples of 8
Output Relay
Yn
n = 0~9999
Multiples of 8
Internal Relay
Mn
n = 0~9999
Multiples of 8
Special Relay
Mn
n = 0~9999
Multiples of 8
Step Relay
Sn
n = 0~9999
Multiples of 8
Timer Flag
Tn
n = 0~9999
Counter Flag
Cn
n = 0~9999
6.4.3. Settings of Communication Parameters:
(According to Linked Device)
