CONCH HM Series User Manual

6 Instruction of the Wiring & Setting of Supported Communication Devices
23
HM Series Connection Manual
6.2. Allen Bradley MicroLogix PLC
6.2.1. Register Type & Range:
Register Type
Code Format
Numbering Range of Address
Data Length
Word No.
Bit No.
Output file
O:0.n
n = 0~3
0
Word
Input file
I:1.n
n = 0~3
0
Word
Status file
S2:n
n = 0~65
0
Word
Bit file
B3:n
n = 0~254
0
Word
Timer flag
T4:n.0
n = 0~254
0
Word
Timer Preset Value
T4:n.PRE
n = 0~254
0
Word
Timer Accumulator Value
T4:n.ACC
n = 0~254
0
Word
Counter flag
C5:n.0
n = 0~254
0
Word
Counter Preset Value
C5:n.PRE
n = 0~254
0
Word
Counter Accumulator Value
C5:n.ACC
n = 0~254
0
Word
Control file
R6:n.0
n = 0~254
0
Word
Control Size of Bit Array
R6:n.LEN
n = 0~254
0
Word
Control Reserved file
R6:n.POS
n = 0~254
0
Word
Integer file
N7:n
n = 0~254
0
Word
