6.7 Koyo Direct205 Series ( K-Sequence )
HM Series Connection Manual
6.7. Koyo Direct205 Series ( K-Sequence )
6.7.1. Register Type & Range: (Value Addresses of
Octal Number System)
Register Type
Code Format
Numbering Range of Address
Data Length
Input relay
Xn
n = 0~1760 (Multiples of 20)
Word
Output relay
Yn
n = 0~1760 (Multiples of 20)
Word
Internal relay
Cn
n = 0~3760 (Multiples of 20)
Word
Stages
Sn
n = 0~1760 (Multiples of 20)
Word
Timer relay
Tn
n = 0~360 (Multiples of 20)
Word
Counter relay
CTn
n = 0~360 (Multiples of 20)
Word
Data register
Vn
n = 0~7777
Word
Special relay
SPn
n = 0~760 (Multiples of 20)
Word
Timer current value
TNn
n = 0~377
Word
Counter current value
CNn
n = 0~377
Word
Remote Input
GXn
n = 0~360 (Multiples of 20)
Word
Remote Output
GYn
n = 0~360 (Multiples of 20)
Word
