CONCH HM Series User Manual

18
6.1 HM Series Internal Registers
HM Series Connection Manual
●Curve Control Register (CUCR): CB3
Trigger Flag of Curve Sampling – Trigger Flag #1 ~ #8
Bit Mask
b0
b1
b2
b3
b4
b5
b6
b7
CUCR
CB3.0
CB3.1
CB3.2
CB3.3
CB3.4
CB3.5
CB3.6
CB3.7
Function
T/S_1
T/S_2
T/S_3
T/S_4
T/S_5
T/S_6
T/S_7
T/S_8
T/S－Triggered by PLC or sampling status of the timer.
Reset Controlling Flag of Curves Reset Flag #1 ~ #8
Bit Mask
b8
b9
b10
b11
b12
b13
b14
b15
CUCR
CB3.8
CB3.9
CB3.10
CB3.11
CB3.12
CB3.13
CB3.14
CB3.15
Function
RS_1
RS_2
RS_3
RS_4
RS_5
RS_6
RS_7
RS_8
RS－ Reset Controlling of Curves
●Curve Control Status Register (CUSR): SB3
Triggered Status of Curve Sampling #1 ~ #8
Bit Mask
b0
b1
b2
b3
b4
b5
b6
b7
CUSR
SB3.0
SB3.1
SB3.2
SB3.3
SB3.4
SB3.5
SB3.6
SB3.7
Function
TS_1
TS_2
TS_3
TS_4
TS_5
TS_6
TS_7
TS_8
TS－Triggered by PLC or sampling status of the timer.
Reset Status of Curves #1 ~ #8
Bit Mask
b8
b9
b10
b11
b12
b13
b14
b15
CUSR
SB3.8
SB3.9
SB3.10
SB3.11
SB3.12
SB3.13
SB3.14
SB3.15
Function
RS_1
RS_2
RS_3
RS_4
RS_5
RS_6
RS_7
RS_8
RS－Reset Status of Curves
