CONCH HM Series User Manual

124
6.22 Omron CS/CJ Series (including CP1 Series)
HM Series Connection Manual
6.22.2. Contact Type & Range:
Contact Type
Code Format
Numbering Range of Address
Block
CIO Area
CIOn.b
n = 0~6143, b = 0~15
b = 0
Work Area
Wn.b
n = 0~511, b = 0~15
b = 0
Holding Bit Area
Hn.b
n = 0~1535, b = 0~15
b = 0
Auxiliary Bit Area
An.b
n = 0~959, b = 0~15
b = 0
Timer Area Contact
Tn
n = 0~4095
(Read-only)
Counter Area Contact
Cn
n = 0~4095
(Read-only)
DM Area
Dn.b
n = 0~32767, b = 0~15
b = 0
EM Area
Em.n.b
m = 0~C (Hexadecimal)
n = 0~32767, b = 0~15
b = 0
6.22.3. Settings of Communication Parameters:
(According to Linked Device)
Parameters
Default Value
Setting Range
Device Address
0
0 ~ 31
Communication Mode
RS232
RS232 / RS485 / RS422
Baud Rate
9600 bps
4800 bps ~ 115200 bps
Data Length
7 bits
7 bits / 8 bits
Parity Check
Even
None / Odd / Even
Stop Bit
2 bits
1 bit / 2bits
Command Delay Time
0
0 ~ 1000 ms
HMI Address
Null
