HM Series Connection Manual
●Control Command Status Register (CCSR): SB2
Bit Mask
Function Definition
SB2 b0
Clearing Status of Alarm Records
SB2.b1
Clearing Status of Alarm Counting
SB2.b2
(Reserved)
SB2.b3
(Reserved)
SB2.b4
Triggering Status of Recipe Changing
SB2.b5
Recipe Retrieving Status ( HMI ← PLC )
SB2.b6
Recipe Writing-in Status ( HMI → PLC )
SB2.b7
(Reserved)
SB2.b8 ～ SB2.b10
Authority Level of Present Operator ( 0 ~ 7 )
SB2.b11
(Reserved)
SB2.b12
Alarm Output Status
SB2.b13
Buzzer Controlling Status
SB2.b14
Alarm Contact OFF Complete
SB2.b15
Alarm Contact ON Complete
