CONCH HM Series User Manual

48
6.6 Koyo DirectNET Host (DL/SU Series)
HM Series Connection Manual
V Memory
Vn
n = 41140~41147
Counter Status
n = 41200~41205
Special Relay
n = 41216~41230
Special Relay
6.6.2. Contact Type & Range: (Value Addresses of
Octal Number System)
Contact Type
Code Format
Numbering Range of Address
Block
Input Status
Xn
n = 0~477
Multiples of
10
Output Status
Yn
n = 0~477
Multiples of
10
Control Relay
Cn
n = 0~737
Multiples of
10
Stages
Sn
n = 0~777
Multiples of
10
Timer Status
Tn
n = 0~177
Multiples of
10
Counter Status
CTn
n = 0~177
Multiples of
10
Special Relay
SPn
n = 0~137
n = 320~617
Multiples of
10
Remote IN
GXn
n = 0~777
Multiples of
10
6.6.3. Settings of Communication Parameters:
(According to Linked Device)
Parameters
Default Value
Setting Range
Device Address
1
1 ~ 90
