HM Series Connection Manual
6.9. LG Master-K CNet
6.9.1. Register Type & Range:
Register Type
Code Format
Numbering Range of Address
Data Length
I/O relay
Pn
n = 0~63
Word
Auxiliary relay
Mn
n = 0~191
Word
Data register
Dn
n = 0~9999
Word
Timer elapsed value
Tn
n = 0~255
Word
Counter elapsed value
Cn
n = 0~255
Word
Keep relay
Kn
n = 0~31
Word
Link relay
Ln
n = 0~63
Word
Special relay
Fn
n = 0~63
Word
Step Controller
Sn
n = 0~99
Word
6.9.2. Contact Type & Range:
Contact Type
Code Format
Numbering Range of Address
Block
I/O relay
Pnb
n = 0~63, b = 0~15
b = 0
Auxiliary relay
Mnb
n = 0~191, b = 0~15
b = 0
Timer relay
Tn
n = 0~255
Counter relay
Cn
n = 0~255
Keep relay
Knb
n = 0~31, b = 0~15
b = 0
Link relay
Lnb
n = 0~63, b = 0~15
b = 0
Special relay
Fnb
n = 0~63, b = 0~15
b = 0
