6.13 Mitsubishi FX / FX2n Computer Link
HM Series Connection Manual
6.13. Mitsubishi FX / FX2n Computer Link
6.13.1. Register Type & Range:
Register Type
Code
Format
Numbering Range of Address
Data
Length
Auxiliary Relay
Mn
n = 0~3056 (Must be multiples of 8)
Word
Special Auxiliary Relay
Mn
n = 8000~8240 (Must be multiples of 8)
Word
State Relay
Sn
n = 0~984 (Must be multiples of 8)
Word
Input Relay
Xn
n = 0~360 (Octal system, must be multiples of 10)
Word
Ouput Relay
Yn
n = 0~360 (Octal system, must be multiples of 10)
Word
Timer PV
Tn
n = 0~255
Word
16-bit Counter PV
Cn
n = 0~199
Word
32-bit Counter PV
Cn
n = 200~255
DWord
Data Register
Dn
n = 0~7999
Word
Special Data Register
Dn
n = 8000~8255
Word
6.13.2. Contact Type & Range:
Contact Type
Code
Format
Numbering Range of Address
Block
Auxiliary Relay
Mn
n = 0~3071
Multiples of 8
Special Auxiliary Relay
Mn
n = 8000~8255
Multiples of 8
State Relay
Sn
n = 0~999
Multiples of 8
Input Relay
Xn
n = 0~377 (Octal system)
Multiples of
10
Ouput Relay
Yn
n = 0~377 (Octal system)
Multiples of
10
Timer Flag
Tn
n = 0~255
Counter Flag
Cn
n = 0~255
