CONCH HM Series User Manual

84
6.14 Mitsubishi FX3U Series
HM Series Connection Manual
6.14. Mitsubishi FX3U Series
6.14.1. Register Type & Range:
Register Type
Code
Format
Numbering Range of Address
Data Length
Auxiliary Relay
Mn
n = 0~7664 (Must be multiples of 8)
Word
Special Auxiliary Relay
Mn
n = 8000~8496 (Must be multiples of 8)
Word
State Relay
Sn
n = 0~4080 (Must be multiples of 8)
Word
Input Relay
Xn
n = 0~350 (Octal system, must be multiples of
10)
Word
Ouput Relay
Yn
n = 0~350 (Octal system, must be multiples of
10)
Word
Timer PV
Tn
n = 0~511
Word
16-bit Counter PV
Cn
n = 0~199
Word
32-bit Counter PV
Cn
n = 200~255
DWord
Data Register
Dn
n = 0~7999
Word
Special Data Register
Dn
n = 8000~8511
Word
Extension Register
Rn
n = 0~32767
6.14.2. Contact Type & Range:
Contact Type
Code
Format
Numbering Range of Address
Block
Auxiliary Relay
Mn
n = 0~7679
Multiples of
8
Special Auxiliary Relay
Mn
n = 8000~8511
Multiples of
8
State Relay
Sn
n = 0~4095
Multiples of
8
