HM Series Connection Manual
6.1.3. Function Definitions of System Controlling
Status Registers:
●System Controlling Area Register: (CB0 ~ CB31; 32 words max.)
Word Register
Function
CB0
Screen Change Control Register ( SNCR )
CB1
Screen Command Flag Register ( SCFR )
CB2
Control Command Flag Register ( CCFR )
CB3
Curve Control Register ( CUCR )
CB4
Record Buffer Controlling Register1 (LCR1: LB1 ~ LB4)
CB5
Record Buffer Controlling Register2 (LCR2: LB5 ~ LB8)
CB6
Record Buffer Controlling Register3 (LCR3: LB9 ~ LB12)
CB7
Recipe Group Numbering Registers ( RNIR )
CB8 ～ CB31
User-Applying Controlling Register ( UACR )
●System Status Area Register: (SB0 ~ SB31; 32 words max.)
Word Register
Function
SB0
Screen Status Register ( SNSR )
SB1
Screen Command Status Register ( SCSR )
SB2
Controlling Command Status Register ( CCSR )
SB3
Curve Controlling Status Register ( CUSR )
SB4
Record Buffer Status Register1 ( LSR1: LB1 ~ LB4 )
SB5
Record Buffer Status Register2 ( LSR2: LB5 ~ LB8 )
SB6
Record Buffer Status Register3 ( LSR3: LB9 ~ LB12 )
SB7
Recipe Numbering Status Register ( RNSR )
SB8 ～ SB31
User’s Applying Status Register ( UASR )
●Screen Change Control Register (SNCR): CB0
