6.16 Mitsubishi A Series A1SH CPU
HM Series Connection Manual
6.16.2. Contact Type & Range:
Contact Type
Code Format
Numbering Range of Address
Block
Input Relay
Xn
n = 0~7FF (Hexadecimal)
Multiples of
10
Output Relay
Yn
n = 0~7FF (Hexadecimal)
Multiples of
10
Link Relay
Bn
n = 0~3FF (Hexadecimal)
Multiples of
10
Internal Relay
Mn
n = 0~999
Multiples of
16
Special Relay
Mn
n = 9000~9255
Latch Relay
Ln
n = 0~2047
Multiples of
16
Annunciator
Fn
n = 0~255
Multiples of
16
Timer Contact
Tn
n = 0~255
Timer Coil
TCn
n = 0~255
Counter Contact
Cn
n = 0~255
Counter Coil
CCn
n = 0~255
Peripherial Input Relay
PXn
n = 0~255
Multiples of
16
Step Relay
Sn
n = 0~2047
Multiples of
16
