6.11 Matsushita FP Series
HM Series Connection Manual
6.11. Matsushita FP Series
6.11.1. Register Type & Range:
Register Type
Code Format
Numbering Range of Address
Data Length
Internal Relay
WRn
n = 0~875
Word
Special Internal Relay
WRn
n = 900~910
Word
Link Relay
WLn
n = 0~639
Word
External Input Relay
WXn
n = 0~255
Word
External Output Relay
WYn
n = 0~255
Word
Timer/Counter P.V.
EVn
n = 0~2047
Word
Timer/Counter S.V.
SVn
n = 0~2047
Word
Data Register
DTn
n = 0~32764
Word
Special Data Register
DTn
n = 9000~9255
Word
Link Data Register
LDn
n = 0~8447
Word
File Register
FLn
n = 0~32764
Word
6.11.2. Contact Type & Range:
Contact Type
Code Format
Numbering Range of Address
Block
Internal Relay
Rnb
n = 0~875, b = 0~F (Hexadecimal)
b = 0
Special Internal Relay
Rnb
n = 900~910, b = 0~F (Hexadecimal)
b = 0
Link Relay
Lnb
n = 0~639, b = 0~F (Hexadecimal)
b = 0
External Input Relay
Xnb
n = 0~255, b = 0~F (Hexadecimal)
b = 0
External Output Relay
Ynb
n = 0~255, b = 0~F (Hexadecimal)
b = 0
Timer Flag Contact
Tn
n = 0~2047
Counter Flag Contact
Cn
n = 0~2047
6.11.3. Settings of Communication Parameters:
(According to Linked Device)
Parameters
Default Value
Setting Range
