CONCH HM Series User Manual

128
6.23 Siemens S7-200 PPI
HM Series Connection Manual
6.23.2. Contact Type & Range:
Contact Type
Code Format
Numbering Range of Address
Block
Input Image
In.b
n = 0~15, b = 0~7
b = 0
Output Image
Qn.b
n = 0~15, b = 0~7
b = 0
Internal Relay
Mn.b
n = 0~100, b = 0~7
b = 0
Timer bit
Tn
n = 0~255
Counter bit
Cn
n = 0~255
Special Relay
SMn.b
n = 0~200, b = 0~7
b = 0
Data Area bit
Vn.b
n = 0~9999, b = 0~7
b = 0
Special M
Sn.b
n = 0~100, b = 0~7
b = 0
6.23.3. Settings of Communication Parameters:
(According to Linked Device)
Parameters
Default Value
Setting Range
Device Address
2
Communication Mode
RS485
Baud Rate
9600 bps
9600 bps / 19200 bps
Data Length
8 bits
Parity Check
Even
Stop Bit
1 bit
Command Delay Time
0
0 ~ 1000 ms
HMI Address
Null
