6.2 Allen Bradley MicroLogix PLC
HM Series Connection Manual
6.2.2. Contact Type & Range:
Contact Type
Code Format
Numbering Range of Address
Block
Word No.
Bit No.
Output file
O:0.n/b
n = 0~3
b = 0~15
b = 0
Input file
I:1.n/b
n = 0~3
b = 0~15
b = 0
Status file
S2:n/b
n = 0~65
b = 0~15
b = 0
Bit file
B3:n/b
n = 0~254
b = 0~15
b = 0
Timer flag
T4:n.0/b
n = 0~254
b = 0~15
b = 0
T4:n.0/EN
EN = 15
T4:n.0/TT
TT = 14
T4:n.0/DN
DN = 13
Timer Preset Value
T4:n.PRE/b
n = 0~254
b = 0~15
Timer Accumulator Value
T4:n.ACC/b
n = 0~254
b = 0~15
Counter flag
C5:n.0/b
n = 0~254
b = 0~15
b = 0
C5:n.0/CU
CU = 15
C5:n.0/CD
CD = 14
C5:n.0/DN
DN = 13
C5:n.0/OV
OV = 12
C5:n.0/UN
UN = 11
C5:n.0/UA
UA = 10
Counter Preset Value
C5:n.PRE/b
n = 0~254
b = 0~15
Counter Accumulator Value
C5:n.ACC/b
n = 0~254
b = 0~15
Control file
R6:n.0/b
n = 0~254
b = 0~15
b = 0
R6:n.0/EN
EN = 15
R6:n.0/DN
DN = 13
R6:n.0/ER
ER = 11
R6:n.0/UL
UL = 10
Control file
R6:n.0/IN
IN = 9
