HM Series Connection Manual
6.6. Koyo DirectNET Host (DL/SU Series)
6.6.1. Register Type & Ranger: (Value Addresses of
Octal Number System)
Register Type
Code
Format
Numbering Range of Address
Data Length
Timer Current Value
TNn
n = 0~177
Word
Counter Current Value
CNn
n = 0~177
Word
Input Status
Xn
n = 0~460 (must be multiples of 10)
Word
Output Status
Yn
n = 0~460 (must be multiples of 10)
Word
Control Relay
Cn
n = 0~720 (must be multiples of 10)
Word
Stages
Sn
n = 0~760 (must be multiples of 10)
Word
Timer Status
Tn
n = 0~160 (must be multiples of 10)
Word
Counter Status
CTn
n = 0~160 (must be multiples of 10)
Word
Special Relay
SPn
n = 0~120 (must be multiples of 10)
n = 320~600 (must be multiples of 10)
Word
Remote IN
GXn
n = 0~760 (must be multiples of 10)
Word
V Memory
Vn
n = 0~177
Timer Current Value
Word
n = 1000~1177
Counter Current Value
n = 1400~7777
Data Register
n = 40000~40037
Remote IN
n = 40400~40423
Input Status
n = 40500~40523
Output Status
n = 40600~40635
Control Relay
n = 41000~41027
Stages
n = 41100~41107
Timer Status
