CONCH HM Series - Omron CS;CJ Series Communication

6 Instruction of the Wiring & Setting of Supported Communication Devices
123
HM Series Connection Manual
6.22. Omron CS/CJ Series (including CP1
Series)
6.22.1. Register Type & Range:
Register Type
Code Format
Numbering Range of Address
Data Length
CIO Area
CIOn
n = 0~6143
Word
Work Area
Wn
n = 0~511
Word
Holding Bit Area
Hn
n = 0~1535
Word
Auxiliary Bit Area
An
n = 0~959
Word
DM Area
Dn
n = 0~32767
Word
Timer Area PV
Tn
n = 0~4095
Word
Counter Area PV
Cn
n = 0~4095
Word
EM Area
Em.n
m = 0~C (Hexadecimal)
n = 0~32767
Word
EM Current Bank
EMn
n = 0~32767
Word
Task Flag
TKn
n = 0~31
Byte
Index Register
IRn
n = 0~15
DWord
Data Register
DRn
n = 0~15
Word
