CONCH HM Series User Manual

6 Instruction of the Wiring & Setting of Supported Communication Devices
119
HM Series Connection Manual
6.21. Omron C Series ( CPM1A / TPM1A )
6.21.1. Register Type & Range:
Register Type
Code Format
Numbering Range of Address
Data Length
IR area
IRn
n = 0~511
Word
HR area
HRn
n = 0~99
Word
AR area
ARn
n = 0~27
Word
LR area
LRn
n = 0~63
Word
TC area (current value)
TCn
n = 0~511
Word
DM area
DMn
n = 0~6655
Word
6.21.2. Contact Type & Range:
Contact Type
Code Format
Numbering Range of Address
Block
IR area
IRnb
n = 0~511
b = 0~15
b = 0
HR area
HRnb
n = 0~99
b = 0~15
b = 0
AR area
ARnb
n = 0~27
b = 0~15
b = 0
LR area
LRnb
n = 0~63
b = 0~15
b = 0
Timer/Counter Coil
TCn
n = 0~511
