CONCH HM Series - Page 52

42
6.4 Facon FBs Series PLC
HM Series Connection Manual
 COM2 ( RS232 )
HM Series Terminal
PLC Terminal
25Pin D-SUB Male
15Pin D-SUB Male
P14 P1
25P
(Male Adapter)
P1 P9
15P
(Male Adapter)
2
1
6
RXD
TXD
GND
3
2
7
TXD
RXD
GND
FG FG
3
4
RTS
CTS
