78 Product specication
9.2 Operating data
Control steam output
– active 0…5 VDC, 1…5 VDC, 0…10 VDC, 2…10 VDC, 0…20 VDC, 0…16 VDC,
3.2…16 VDC, 0…20 mADC, 4…20 mADC
– passive all potentiometric humidity sensors from 140 Ω…10 kΩ
– On/Off control <2.5 VDC --> Off; ≥2.5 VDC…20 VDC --> On
Duct air pressure -0.8 kPa to 1.5 kPa; upto 10.0 kPa with optional overpressure kit
Admissible ambient temperature 1...40 °C
Admissible ambient humidity 1...75 %rh (non-condensing)
Water supply
– Admissible water supply pressure 1...10 bar (with optional drain water cooling 2...10 bar)
– Admissible Feed temperature 1...40 °C (with optional drain water cooling 1...25 °C)
– Water quality Untreated drinking water with a conductivity of 125 to 1250 μS/cm)
Water drain
– Drain water temperature 80...90 °C (with optional drain water cooling <60 °C)
Protection class IP21
9.3 Connections/Dimensions/Weights
Water supply connector G 3/4»
Water drain connector ø30 mm
Steam connector ø45.0 mm
Housing dimensions
– Small unit (S) - H x W x D 670 mm x 420 mm x 370 mm
– Medium unit (M) - H x W x D 780 mm x 530 mm x 406 mm
– Large unit (L) - H x W x D 780 mm x 1000 mm x 406 mm
Unit weights
– Small unit (S) - Net weight/operating weight 24.1 kg / 34.1 kg
– Medium unit (M) - Net weight/operating weight 35.5 kg / 58.6 kg
– Large unit (L) - Net weight/operating weight 57.3 kg / 105.0 kg
9.4 Certicates
Certicates CE, VDE
