53Maintenance
6.3 Removing and installing components for maintenance
6.3.1 Removal and installation of the steam cylinder
WARNING!
Danger of burning!
Before removal of the steam cylinder ensure the steam cylinder is empty and has cooled down, that
no more burning danger exists.
1. Loosen retaining screw of the front door on the steam cylinder side of the unit using a screwdriver,
then remove the front door.
2. Free the upper hose clamp of the steam outlet hose using a screwdriver and pull the hose downwards
from the steam connector.
3. Remove all plugs from the electrodes and from the level sensor. Then, press the tab of the cable tie
holding the cylinder in place and pull the cable tie open.
4. Carefully lift the steam cylinder out of steam cylinder receptacle and remove it towards the front of
the unit.
2
4
1
3
