Condair Sigma - Installation Overviews

23Mounting and installation work
5.2 Installation overviews
125...1250 µS/cm
1...10 bar
1...40 °C
≥ 40 mm
min. 50 cm
ø14/7 mm
G 3/4"
G 1/2"
G 3/8"
ø 30 mm
Z261
Rmin. 300 mm
Rmin. 300 mm
min. 300 mm
min. 15 %
–
min. 15 %
–
min. 15 %
+
min. 15 %
+
DS35
DS22
W22
DDL22
DDS22
W35
DDL35
W22
DDL22
DDS22
W35
DDL35
Mounting the unit: see chapter 5.3
Steam installation: see chapter 5.4
Water installation: see chapter 5.5
Electric installation: see chapter 5.6
Abb. 8: Installation overview
