Condair Sigma - Removal and Installation of the Drain Valve

65Maintenance
7.3.4 Removal and installation of the drain valve
For removing the drain valve the steam cylinder must be removed rst (see chapter 7.3.1).
1. Detach electric cables (polarity of the cables must not be observed).
2. Release hose clamp and remove the hose from the connector.
3. Loosen the two screws with Phillips screwdriver, then remove the drain valve.
4. Disassemble the drain valve.
The assembly and the installation of the drain valve follows the reverse sequence. Before assembling
the valve, check all O-rings and gaskets for damage and replace if necessary.
4
22
3
1
