Condair Sigma - Wiring Diagram Condair Sigma 5-65 Kg;H

42 Mounting and installation work
Smart Card
red yellow green
F1 (6.3 AT)
CONT.SIGN
V+ IN GND
X2 X3
VD
MAIN SUPPLY
L1 N SC1SC2
LEV.SENSOR
J1
X1
CURRENT SENSOR
CPU BOARD
1 2
On/Off
JP1 must be plugged
B1
K
J
Q3
230 V/1~/50..60 Hz
L1 N
F3
On/Off Mode
JP1
+ –
0-10V
A1
H1
A2
A3
F4
230V
L1’
1 2 3 4 5 6 7 8 9 10
Error Service Steam Unit On
Cylinder
Drain Factor
Power Limit
Manual Drain
Low Conduct.
Standby Drain
Force Drain
Cylinder A/D
GFCI-Mode
Offset
Settings
0
DriverRFI
ON
1 2 3 4 5 6
J8
J1
V+ IN GND
X5
X7
X8
X4
1 2 3 4
SWITCH
1 2 3 4
INLET
1 2
CONTACTORDRAIN
max.
T /
PE
S1
S2
S3
S4
L1
Q2
K1
THV
F2
L1 L2 L3
L1 L2 L3
L1 L2 L3
400 V/3~/50..60 Hz
230 V/3~/50..60 Hz
Q2
F2
L1 N PE
PE
PE
230 V/1~/50..60 Hz
Q2
F2
L1 L2
400 V/2~/50..60 Hz
ES4
ext.
400 V/3~N/50..60 Hz
F2
Q2
400 V/3~/50..60 Hz
F2
Q2
L2 L3 PEL1
L2 L3 PEN
L1
L2 L3L1
N PEL1
L2 L3L1
N PEL1
5.6.3 Wiring diagram Condair Sigma 5-65 kg/h
A1 Continuous controller (active 0-10V) or control signal input
from Condair Delta SPA Control Box
A2 On/Off controller (passive 24VDC), set jumper on JP1
A3 On/Off control (active 230VAC)
B1 Ventilation interlock
B2 Airow monitor
B3 Safety humidistat / Safety thermostat
F1 Internal fuse power board (6.3 A, slow acting)
F2
External fuse heating voltage supply (fuse values see
table in chapter 5.6.4.5)
F3 External fuse control voltage supply
F4 External fuse 230V On/Off control
H1 Remote operating and fault indication (option "RFI")
J Short circuited, if no external monitoring devices are
connected
JP1 Jumper On/Off mode
K External safety chain (230V/5A)
K1 Main contactor (for connecting the heating voltage supply
to the unit)
Q2 External electrical isolator heating voltage supply
Q3 External electrical isolator control voltage supply
S1 Rotary switch "Cylinder type"
S2 Potentiometer "Drain factor"
S3 Potentiometer "Power limitation"
S4 DIP switch "General unit settings"
THV Connection terminal heating voltage (option THV)
X1 Connection terminal control signal
X2 Connection terminal On/Off control active
X3 Connection terminal control voltage
Control board Power board
Option TR (3Ph)
Option CVI (3Ph+N)
6.3 A, slow acting
6.3 A,
slow acting
